    Full Automatic multiple blades rip sawmill Production Line for round logs sawing machines

    Ask Lasest Price
    Brand Name : SH
    Certification : ISO9001
    Model Number : SHYM200,SHYM250, SHYM300, SHYM450
    Price : USD38,000-USD95,000/Unit
    Delivery Time : within 20 days
    Payment Terms : T/T
    Supply Ability : 100units/year
    • Product Details
    • Company Profile

    Full Automatic multiple blades rip sawmill Production Line for round logs sawing machines

    Multiple Blades Rip Sawmill Production Line
    The max sawing wood diameter is 200mm , Max Loading Log Length3000mm

    Full Automatic multiple blades rip sawmill Production Line for round logs sawing machines

    Full Automatic multiple blades rip sawmill Production Line for round logs sawing machines

    1Log Loading Deck
    Max Loading Log Length2500MM
    Max Loading Log Diameter350MM
    Horizontal Loading Belt2
    Distance Between Loading Belt800mm
    Motor Power2.2KW
    Log Cutting Multiple Blades Sawmill
    Sawing Log Diameter200mm
    Min Sawing Log Length1000mm
    Spindle speed2800r/min
    Main Motor power22KW*2
    Feeding Motor2.5KW
    Saw Blade Quantity2-10 pieces
    Saw Blade Diameter305mm
    Variable Frequency Speed Adjustable Feeding,
    Axles Center Water Cooling System,
    one set Spacer pad,6 pieces saw blade.
    Circular Saw Blade Diameter305 MM

    Full Automatic multiple blades rip sawmill Production Line for round logs sawing machinesFull Automatic multiple blades rip sawmill Production Line for round logs sawing machines

    Full Automatic multiple blades rip sawmill Production Line for round logs sawing machines


    2Wood conveyor
    Max Loading Log Length2500MM
    Horizontal Loading Belt2
    Distance Between Loading Belt800mm
    Motor Power2.2KW

    Full Automatic multiple blades rip sawmill Production Line for round logs sawing machines

    3,6CS600-6000 Conveyor Belt (With power)
    Length6000mm
    600mm
    Width
    1.5KW

    Full Automatic multiple blades rip sawmill Production Line for round logs sawing machines

    5Multiple Blade Saw Machine
    Max. Sawing width250mm
    Max. sawing thickness120mm
    Min Sawing length600mm
    Spindle Speed2800 r/min
    Motor22KW*2
    Feed Motor2.2KW
    Saw Blade Diameter230mm
    Saw Blade Quantity2-10 pieces
    Cooling Water Pressure0.3-0.6PA
    Including:Variable Frequency Speed Adjustable Feeding,
    Axles Water Cooling System,Spacer pad,6 pieces saw blade.
    Circular Saw Blade Diameter230MM

    Full Automatic multiple blades rip sawmill Production Line for round logs sawing machines

    7,9Offcuts Circular Sawmill
    Max Sawing Wood Width200MM
    Motor Power7.5KW*2
    Feeding SpeedVariable Frequency
    Circular Saw Blade Diameter305MM
    Multiple Blade Rip Sawmill
    Max Sawing Wood Thickness50mm
    Max Sawing Wood Width380mm
    Saw Blade Diameter230mm
    Motor Power7.5KW
    Saw Blade Quantity1P-5P
    Spindle Speed5800/min
    Circular Saw Blade Diameter230mm

    Full Automatic multiple blades rip sawmill Production Line for round logs sawing machines

    Full Automatic multiple blades rip sawmill Production Line for round logs sawing machines

    10Automatic Board Edger
    Max. sawing thickness35mm
    Max Cutting Log Length3000mm
    Max Cutting Plank Width200mm
    saw heads quantity4
    Motor Power2.2KW*4

    Full Automatic multiple blades rip sawmill Production Line for round logs sawing machines

    4,8CS600-2000 Conveyor Belt (No power)
    Length2000mm
    600mm

    Full Automatic multiple blades rip sawmill Production Line for round logs sawing machines

    11Automatic Carbide Circular Saw Blade Sharpener
    Saw Blade Diameter125-800MM
    Feeding Speed0-24 Teeth /Minute
    Grinding Wheel150MM
    Grinding Wheel Motor370W

    Full Automatic multiple blades rip sawmill Production Line for round logs sawing machines
