| Capacity 30cbm wood drying kiln Configuration List |
| Kiln (ZCM-30) |
| No. | Name | Description: steam hot air boiler heating | QTY |
| 1 | Kiln | Drying products:Suitable for drying of various woods, as well as
wood sterilization, insecticide and wood heat treatment
Kiln Inner size, L: 6500mm, W: 4500mm , H: 4000mm
Kiln wall materials:The inner wall is made of all-aluminum for
anti-corrosion and high temperature resistance The outer wall is made of color steel plate, and the middle
insulation fiber cotton insulation. Rock wool insulation 50mm thick
| 1 PC |
| Heat Source System |
| 1 | Boiler | 300000 kcal steam hot air boiler Materials: welded with special steel plate. 300000 kcal steam hot
air boiler, woods usage (forcing type, air outlet temperature of
boiler: 180°-200°, main fuel: wood, sawdust, coal, etc. Materials
of boiler insulation: special steel plate for full steel boiler) | 1 set |
| 2 | Steam generator | materials:welded with special steel plate, thickness: 8mm | 1 unit |
| 3 | Chimney | Materials: welded with special steel plate. φ240mm, length
:6700mm,each piece length 3350mm x2pcs , Diameter 280mm, wall thickness 2mm | 2pcs |
| 4 | Automatic exhaust valves | Materials: Special cast iron | 1 pc |
| 5 | Glass tube | φ20mm, Length: 450mm | 2pcs |
| 6 | Water tank | Thickness 8.0mm,capacity: 200L. materials: welded with special
steel plate | 1 unit |
| 7 | Tap | Materials: cast steel type | 1 pc |
| 8 | Steam valves | Materials: cast steel type | 1 pc |
| 9 | Water bucket | Materials: steel plate type | 1 pc |
| Pipe System |
| 1 | Inlet pipe | Φ318mm. materials: full welded with steel plate | 1 unit |
| 2 | Return air duct | Φ318mm. materials: full welded with steel plate | 1 unit |
| 3 | Recycling part | Φ318mm. materials: full welded with steel plate | 1 unit |
| 4 | Bends | Φ318mm. materials: full welded with steel plate | 4pcs |
| 5 | Air outlet iron plate | Φ318mm. materials: full welded with steel plate | 1 unit |
| 6 | Inlet pipe flange | Φ318mm. materials: full welded with steel plate | 1 unit |
| 7 | Return air duct flange | Φ318mm. materials: full welded with steel plate | 1 unit |
| 8 | Heat outlet pipe | Φ318mm. materials: full welded with steel plate | 1 unit |
| Air-blower System |
| 1 | High temperature main blower | power: 4.00KW. Materials: full carbon steel , Volute fan | 1 set |
2
| Axial flow blower with high temperature and high humidity | power:1.50KW, dia:850mm. materials: full aluminum | 3 sets
|
| Control System |
| 1 | Thermometer of outlet | Materials: stainless steel , temperature: 300C° | 1 pc |
| 2 | Thermonuclear | stainless steel | 1 pc |
| 3 | thermometer | Digital showing | 1 pc |
| 4 | Control cabinet | Full automatic controlling. Inner electric parts are made by Chint | 1 set |
| Exhaust moisture system |
| 1 | Exhaust moisture system | Materials: full welded with steel plate, thickness 2mm,φ240mm | 1 unit |
| 2 | Steel wire rope | Materials: oil wick | 1 unit |
| 3 | Cork | Materials: full copper | 1 unit |
| 4 | Re-tractor of moisture exhaust hole | Materials: steel type, thickness : 2mm | 1 unit |
| 5 | Support bar of moisture exhaust hole | Materials: steel type, thickness : 2mm | 1 unit |
| 6 | Deflector | Materials: full aluminum | 1 unit |
| 7 | Windshield | Materials: full aluminum | 1 unit |
| 8 | Deflector skeleton | Materials: full steel | 1 unit |
| 9 | Windshield skeleton | Materials: full steel | 1 unit |
| Thermal insulation door |
| 1 | thermal insulation door | The inner wall is made of all-aluminum for anti-corrosion and high
temperature resistance The outer wall is made of color steel plate, and the middle
insulation fiber cotton insulation. | 1unit |
| 2 | Door opener | Material: full steel | 1unit |
| 3 | Door parts | Material: full steel | 1unit |
| 4 | Door hinge | Material: full steel | 1unit |
