Semi Automatic Horizontal Wood Stringer Pallet Making Machine Pallet Nailing Machine

Ask Lasest Price
Brand Name :	SH
Model Number :	AWPN-1500, AWPN-1400, etc
Certification :	ISO9001
Price :	US $4,200 - 21,500 / Set
Payment Terms :	T/T, Western Union
Supply Ability :	1000sets/year of Pallet nailing machine
Delivery Time :	within 20 days

Add to Cart

Product Details
Company Profile

Semi Automatic Horizontal Wood Stringer Pallet Making Machine Pallet Nailing Machine

Semi-Automatic Horizontal Wood Pallet Nailing Machine

Technical data

Model	AWPN-1500
Wood pallet length	600-1300mm
Wood pallet width	800-1700mm
Feeding mode	Touching screen auto setworks
Palletizing mode	Automatic
Operational mode	Pneumatic operation
Voltage	380V,480V or other
Air pressure	0.8MPA
Tank size	0.2 cubic
Nail gun speed	7 times /second.
Production efficiency	1-2pcs /min
Apply a nail	Less than 90mm
Number of nail guns	3P OR 4P
Palletizing quantity	15P
Weight	2000kg

Detailed Images

Semi Automatic Horizontal Wood Stringer Pallet Making Machine Pallet Nailing Machine

Other Hot Selling Products

A universal pneumatic nailing table, Pneumatico PT-1700 features an adjustable working top, pneumatic clamping of support elements (blocks or stringers), and pneumatic lift of the pallet towards the operator.

Technical specifications:

Model	PT-1700	PT-3400
Wood pallet length	600-1300mm	700-1500mm
Wood pallet width	800-1700mm	900-3400mm
Operational mode	Pneumatic operation	Pneumatic operation
Air pressure	0.8MPA	0.8MPA
Production efficiency	30-40pcs /h	20-30pcs /h
Number of beams	3p (or customized)	5p (or customized)
Number of nail guns	1P (CN70) American Stanley staple gun	1P (CN70) American Stanley staple gun
Weight	440kg	840kg
Size	22509801900mm	405010502100mm

Semi Automatic Horizontal Wood Stringer Pallet Making Machine Pallet Nailing Machine

Automatic Wood Pallet Nailing Machine with Automatic palletizer

-- USA and National Style Wooden Pallets
-- PLC & Touch Screen control,Pneumatic Operation
-- Manual Feeding,Automatic Nailing and Automatic Stacking
-- Automatic Pallet Lifting Device,Automatic Counting Function on
the display interface of the pallet nailing machine. Can store 16 Pallets*2.
-- After the nailing process,The pallets are turned over to the
stacking platform automatically.
-- Convenient for forklift transport.
-- Save time and space.
-- Technical data
ModelAWPN-1300
Wood pallet length600-1300mm
Wood pallet width800-1300mm
Working modeAutomatic feeding and stacking
Operation modeTouch screen
Operational modePneumatic operation
Voltage and power220V/ 2kw Servo motor
Air pressure0.8MPA
Tank size0.2 cubic
Nail gun speed7 times /second.
Production efficiency1-2pcs /min
Apply a nailLess than 90mm
Number of nail guns3P OR 4P
Weight2000kg
SizeHost machine 1660*1970*2217mm
Stacking 2945*2054*1410

Related Products
Pallet Notcher

ModelWPN-1WPN-2
Power15kw30kw
Material of knifeAlloyAlloy
Capacity600-800pics/h1800pics/h
Processing sizeWood pallet length: max 1800mmWood pallet length: max 1400mm
Wood pallet width: 160mmWood pallet width: max 90mm
Wood pallet thickness:40-60mmWood pallet thickness: 40-60mm
Slot depth: <45mmSlot depth: <45mm
Slot width: 200-230mmSlot width: 200-230mm
Machine size1200*1100*1200mm2300*1300*1300mm
Machine wight400kg1000kg
FeatureSlot smooth, size consistent
Apply for many kinds of slots, also can customized.

Multi Blades Rip Saw
